Soak Pad Making Machine

Description:
Meat/fresh food soak pad machine is a dedicated production line machine for producing soak pad. It’s committed to placing several layers of material (SAP, Paper or Non woven fabric ) together by gluing in hi-speed. These pads are crucial for absorbing and retaining liquids in industrial and household applications.

Specifications:
1.Soak pad size:
Width60-230mm
Length 55-310mm
1) Structure: surface layer（airlaid paper） + absorption core(fluff pulp+down tissue paper) + bottom layer (airlaid)
2) The surface layer is on the top and the bottom film is on the bottom;
2. Production line speed:
1) Design speed (empty vehicle running speed): 800 pieces/minute
2) Stable production speed: 500~600 pieces/minute
3. Product qualification rate: ≥98% (according to the acceptance standard, the ratio of qualified product output to total output. Does not include waste and defective products generated by glue machine, raw materials and replacement materials)
4. Power supply requirements:
1) 380V; 50Hz; 120 square three-phase four-wire + ground wire
2) Installed capacity (excluding hot melt glue machine and dust collector): about 120KW (for reference only, subject to actual design)
5. Air supply requirements: 0.6-0.8Mpa; 2-3 cubic meters/minute (37KW air compressor is recommended) (the buyer prepares the air source by himself, and the air pipe joint is 1 inch)
6. Equipment footprint (length* width * height): 17 * 6 * 3.5m (for reference only)
7. Equipment weight: about 30 tons (for reference only)
6.Others:
Overall dimension: Lenth17*Width6*Height3.5m
Net weight:30T
